GAIA Converter offers a complete range of Front-End elements to protect and adapt the power conversion stage. These Front-End Modules are designed to allow power engineers to ease the development of complex architectures and decrease the time-to-market of projects.

The Front-End performs input filtering and shaping of the input network, including the following functions:

  • EMI filter
  • Reverse polarity
  • Surge limiter
  • Under voltage limiter
  • Inrush current limitation
  • Hold up: Transparency during momentary input bus interruptions – drop outs
  • On/Off
  • Supply of additional signals to ensure perfect power supply management

GAIA Converter offers different types of modules as follows:

Multi function front-end modules
Single function modules
Input Bus Conditioners
series-selection-guide
Fig_LHUG150N _Synop

LHUG-150N synoptic

PGDS-50

PGDS-50 Block Diagram

  • The “Input Bus conditioners” GAIA modules integrate one or more functions of DC/DC Front End like
    EMI filter, reverse polarity, surge limiter, under voltage limiter, inrush current limitation, hold-up: transparency during momentary input bus drop-outs, On/Off, supply of complentary signals to ensure perfect management of power supply



GAIA Converter offers 4 Input Bus Conditioner product lines:

  • Limiter modules (LGDS Series) whose main function is the limitation of high voltage transients
  • Pre-regulated modules (PGDS Series) whose main function is to reduce low voltage and high voltage transients
  • Modules (LHUG) whose main functions, among others, are reverse polarity protection limitation of high voltage transients and Hold Up
  • Modules (FLGH Series) whose main functions, among others, are EMI filtering, reverse polarity protection limitation of high voltage transients and Hold Up
Input Bus Conditioners Series
Reset filters
Characteristics
More characteristics ...
Series Grade Data Sheets Output power RoHS / SnPb Input voltage Max transient input voltage Min transient input voltage Output voltage Output current GAIA Overall package Charger power Power dissipation EMI Filter Spike protection Reverse polarity On/Off Output transient limiter Hold-up Transient elevator Synchronization Hold-up thres. voltage Standard electrical functions
FLHG-60 60W (M) : 10.7 - 100 Vdc (M) : N/A (M) : 11.2 Vdc / [S] 80 Vdc 0.75 A
3.75 A
5.5 / 30 A/s		 2.0-1.6-0.5 MIL-STD-461 N Y Y Y Y N N
FLHGI-90 90 W (R) : 12 - 140 Vdc (R) : 385 Vdc / 20 ms (R) : N/A [S] 12 - 140 Vdc 0.9 A
4 A		 2.0-1.6-0.5 6 W EN 55121, EN-55022 N Y Y Y Y N OUT
LGDS-100 100 W (P) : 9 - 42 Vdc (P) : 202 Vdc / 350 ms (P) : 7 Vdc / 1 s [S] 9 - 42 Vdc 10 A 1.6-1.0-0.5 Basic N N N Y N N N ICL, OCP, OTP
LGDS-300 300 W (O) : 9 - 42 Vdc (O) : 100 Vdc / 50 ms (O) : 7 Vdc / 1 s [S] 9 - 42 Vdc 20 A 1.6-1.0-0.5 3 W Basic N N N Y N N N ICL, OCP, OTP
LGDS-600 600 W (O) : 9 - 36 Vdc
(P) : 9 - 36 Vdc		 (O) : 100 Vdc / 50 ms
(P) : 202 Vdc / 350 ms#Output disconnected		 (O) : N/A
(P) : N/A		 [S] 38 +/- 1 Vdc 35 A 2.0-1.6-0.5 15 W
2.5 W
5 W
7.5 W		 Basic N Y Y Y N N Y
LGDSI-50 50 W (J) : 10 - 36 Vdc
(Q) : 36 - 154 Vdc		 (J) : 85 Vdc / 20 ms
(Q) : 385 Vdc / 20 ms		 (J) : N/A
(Q) : N/A		 [S] 40 max Vdc
1.78 A		 1.6-1.0-0.5 EN-55022 Y Y Y Y N N N ON/OFF, REV.POL
LGDSI-75 75 W (Q) : 43 - 154 Vdc (Q) : 165 Vdc / 1 s (Q) : N/A [S] 40 max Vdc
1.78 A		 1.6-1.0-0.5 EN-55022 Y Y Y Y N N N ON/OFF, REV.POL
LHUG-150 150 W (M) : 11- 80 Vdc (M) : 100 Vdc / 50 ms (M) : N/A [S] 78 max Vdc 10 A 1.6-1.25-0.3 17 W 13 W MIL-STD-461 N Y Y Y Y N IN/OUT UVLO, OPP, SYNC, PF, REV.POL
PGDS-50 50 W (N) : 17 - 37 Vdc
(O) : 12 - 37 Vdc		 (N) : 80 Vdc / 100 ms
(O) : 100 Vdc / 50 ms		 (N) : 10 Vdc / 30 s
(O) : 6 Vdc / 1 s		 [S] 9 - 36 Vdc 1.6-1.0-0.3 Basic N Y Y Y N Y N UVLO, ON/OFF

Values of Inputs: each value is associated to the GAIA Converter code (between brackets)
Values of Outputs: each value is associated to Output Number (between brackets)
GAIA overall package: GAIA specific designation based on dimensions in inches with a tolerance around ± 10% – Consult DataSheet for precise dimensions
Standard electrical functions: Case: Case connection, OVLO: Input overvoltage lockout, UVLO: Input under voltage lockout, OCP: Output over current protection level, OPP: Output over power protection, OVP: Output over voltage protection level, SCP: Output short circuit protection, OTP: Over temperature protection, VIF: Pin for Input Current Ripple Reduction, SYNC: Pin for Synchronisation, TRIM: Pin for adjust ouput voltage, ITRIM: Pin for adjustement ouput current limitation, CC: Pin for capacitor charged signal, CD: Pin for capacitor discharged signal, UVLOadj: Pin for level undervoltage lockout adjust, VREF: Pin for output internal voltage reference, PF: Pin for power fail signal, SENSE: Pin for voltage regulation, REV.POL: Reverse polarity protection, SHARE: Pin for output current parallel sharing
Options: T Screening at start-up -55° C, Y High isolation 3000 Vdc, M On/Off function, S Screening and serialization, F Synchronization function, P Share function

EMI Filters
series-selection-guide

GAIA Converter proposes a full family of state-of-the-art EMI filter modules to fulfill Electromagnetic Interferences (EMI) requirements for Aerospace/Defense applications in a very compact and low loss solution for applications requiring up to 35 amps of input current.

Our EMI Filter modules will help your power supply comply with major standards (MIL-STD-461 rev C, D, E and F – DO-160 rev C, D, E F and G).

All High-Rel filter performances are met across severe environments and operating temperatures of -40°C/+105°C (-55°C also available), and operating and storage temperatures of -55°C/+125°C.

The 100V filter range incorporates an inrush current limiter for the capacitors integrated in the filter. Combined with the “Input Bus Conditioners” modules, they allow the overall architecture of the power supply to respect the current inrush limits imposed by the D0160 and ABD100 standards.

EMI Filters Series
Reset filters
Characteristics
More characteristics ...
Series Grade Data Sheets Output power RoHS / SnPb Input voltage Output current GAIA Overall package DC resistance Standard electrical functions
FGDS-2A-50V 2 A - 50 V 9 - 50 Vdc 2 A 1.25-0.8-0.4 80 mOhm
FGDS-6A-100V 6 A - 100 V 4.5 - 100 Vdc 6 A 1.0-0.8-0.3 30 mOhm ICL
FGDS-10A-50V 10 A - 50 V 9 - 50 Vdc 10 A 1.6-1.0-0.5 11 mOhm
FGDS-12A-100V 12 A - 100 V 4.5 - 100 Vdc 12 A 1.25-1.0-0.3 30 mOhm ICL
FGDS-20A-50V 20 A - 50 V 9 - 50 Vdc 20 A 1.6-1.0-0.65 5 mOhm
FGDS-35A-50V 35 A - 50 V 9 - 50 Vdc 35 A 1.6-1.0-0.65 5 mOhm
FGDS-35A-100V 35 A - 100V 4.5 - 100 Vdc 35 A 1.6-1.0-0.65 5 mOhm

Values of Inputs: each value is associated to the GAIA Converter code (between brackets)
Values of Outputs: each value is associated to Output Number (between brackets)
GAIA overall package: GAIA specific designation based on dimensions in inches with a tolerance around ± 10% – Consult DataSheet for precise dimensions
Standard electrical functions: Case: Case connection, OVLO: Input overvoltage lockout, UVLO: Input under voltage lockout, OCP: Output over current protection level, OPP: Output over power protection, OVP: Output over voltage protection level, SCP: Output short circuit protection, OTP: Over temperature protection, VIF: Pin for Input Current Ripple Reduction, SYNC: Pin for Synchronisation, TRIM: Pin for adjust ouput voltage, ITRIM: Pin for adjustement ouput current limitation, CC: Pin for capacitor charged signal, CD: Pin for capacitor discharged signal, UVLOadj: Pin for level undervoltage lockout adjust, VREF: Pin for output internal voltage reference, PF: Pin for power fail signal, SENSE: Pin for voltage regulation, REV.POL: Reverse polarity protection, SHARE: Pin for output current parallel sharing
Options: T Screening at start-up -55° C, Y High isolation 3000 Vdc, M On/Off function, S Screening and serialization, F Synchronization function, P Share function

High-Reliability Hold Up Modules​
series-selection-guide

The HUGD Series

GAIA Converter Hold-up devices are an alternative solution to the use of batteries or bulk capacitors to negate problems related to momentary input bus drop-outs.

The GAIA Converter HUGD series provides an alternative solution to reduce the amount of capacitance needed by charging the hold-up capacitor at a high voltage value. The device is connected between the input line source bus and DC/DC modules.

FIG HUGD300Synoptic

Fig. HUGD-300 Synoptic

Web-HUGD300TimingDiagram

HUGD-300 Synoptic Timing Diagram

Hold-Up Series
Reset filters
Characteristics
More characteristics ...
Series Grade Data Sheets Output power RoHS / SnPb Input voltage Output current GAIA Overall package Hold-up thres. voltage Max. output V x I Standard electrical functions
HUGD-50 50 W 9 - 40 Vdc 5.6 A 1.6-1.0-0.5 9.5 to 15.3 Vdc 50 W CC, CD, PF, REV.POL
HUGD-300 300 W 8 - 100 Vdc max. 30 A 1.6-1.0-0.5 Adj. 6 to 20 Vdc 300 W CC, CD, PF, REV.POL
